cell

Optional

any power-generating or power-driven machine

AC traction motor

charging generator

Based on battery options

charging interval

8-10 hours (discharge rate of 90%)

technical parameter

rated crew

2 people

system voltage

72v

Length*Width*Height ≧

4400*1600*1950

power of motor

4KW

2600*1600*330 mm

Load-bearing capacity/traction force

1000KG

maximum speed

42KM/H

doors and windows

Manual elevation

Minimum turning radius

6.5m

stop a vehicle by applying the brake

Electronic assistance

maximum gradability

25%

warm braw

Electronic heating air

braking length

≦6m

configure

seat

Cold foam sponge + high-rebound fabric for automobiles

car body

Automotive Process Cockpit

Main beam

High-strength Integrated Stamping Automotive Beam

suspended system

MacPherson independent suspension

car door

Removable and adjustable glass car door

appearance

Digital LCD instrument panel (including vehicle speed, mileage, lights, front/rear turn signals, etc.)

rearview mirror

Manual external rearview mirror

Lighting and signaling

Combined headlight assembly. Combined taillight assembly. Electric horn.

USB+SD insert a card in the slot

sound

Mobile MP3 player with professional speakers

Drive mode

Mid-engine, rear-wheel drive (4X2)

drive system

Stepless speed control system

steering system

Automotive-style steering column, gear-rack type steering system, EPS electronic power steering

rear axle

Spring plate suspension + monocoque reinforced rear axle with 70mm rear axle and 207mm bearings

brake assembly

Front disc and rear drum brakes. Dual-circuit hydraulic braking system. Parking brake device.

tyre

Automotive Vacuum Radial Tire 165/70R14

Hub

Wide-gauge steel wheel rim for automobiles

pigment

silvery
