Tractor Model

LZ4150M3AA

Tractor

√

Fifth Wheel Height@Unload Condition mm

／

Driving Type

4*2

Gear-Box Type

FAST 8JS85F

Front Fitting Radius /Rear SwingRadius mm

／

B, Trailer Model and Basic Configurations：

Product Name

Two Axle Trailer of Car Carrier

Qty

32

Contract NO.

̸

Lead Time

̸

Axle Model/Qty

10TBPW/2

Front Suspension/Rear Suspension

1750/2640

Tire Spec./Qty

235/8

Outframe Beam Spec.

Technical Design

Rim Spec./Qty

9.0*22.5/8

Cross Beam Spec.

Technical Design

I Beam Height（mm）

Technical Design

Floor Type/Thickness（mm）

Technical Design

Main Beam Top and Bottom Flange Plate Thickness (mm)

Technical Design

Body Color(may exist chromatic aberration）

White（Refer to Picture）

Main Beam Web Thickness（mm）

Technical Design

Leaf Spring

8pcs Under Slung

Frame Color

Blue（Refer to Picture）

Landing Gear Type

Technical Design

King Pin Spec.

50# Welded Type

Toolbox Size/Qty

Technical Design

Pump Spec./Qty

4 Units Storage Energy

Relay Valve Spec.

Made in China

PTO

√

Spare Tires Spec./Qty

Two units

ABS System

 4S/2MMade in China

Outside Dimension (Length and width including all metal parts on the trailer, the height means body height）：

（Length*Width*Height, mm）

13750*2550*3950

The describe of cargos and special requirements （cargos name、features、delivery situation、work environment and others): cars

C, Special Requests & Configurations

a, Vehicle Shape: 13750*2550*3950mm, can totally ship 6 cars;

b, The tractor is equipped with PTO device, also arrange pipes and valves for Hydraulic lifting;

c, Wihout Binding belt, block, and Water-drenching Device. With fire extinguisher and  reflective light mark;

d, With two Spare Tire Racks, locate on therear bottom of left & right ;

e, The front gooseneck is equipped with bucket mounting device.
